| Angle (Degrees, 0 degrees = on-axis) | MgCO | Sample | Gain | Angle (De | MgCO | Sample | Gain, Direct Measu | Gain, 3pt average method | Gain, Constant Baseline Method | ||||
| 0 | 16.0 | 20.0 | 1.25 | 75 | 16.0 | 15.0 | 0.938 | 0.938 | 0.938 | ||||
| 15 | 16.0 | 19.0 | 1.19 | 60 | 16.0 | 16.0 | 1.000 | 0.979 | 1.000 | ||||
| 20 | 16.0 | 19.0 | 1.19 | 45 | 16.0 | 16.0 | 1.000 | 1.021 | 1.000 | ||||
| 30 | 16.0 | 17.0 | 1.06 | 30 | 16.0 | 17.0 | 1.063 | 1.083 | 1.063 | ||||
| 45 | 16.0 | 16.0 | 1.00 | 20 | 16.0 | 19.0 | 1.188 | 1.146 | 1.188 | ||||
| 60 | 16.0 | 16.0 | 1.00 | 15 | 16.0 | 19.0 | 1.188 | 1.208 | 1.188 | ||||
| 75 | 16.0 | 15.0 | 0.94 | 0 | 16.0 | 20.0 | 1.250 | 1.250 | 1.250 | ||||
| -15 | 16.0 | 19.0 | 1.19 | -15 | 16.0 | 19.0 | 1.188 | 1.208 | 1.188 | ||||
| -20 | 16.0 | 19.0 | 1.19 | -20 | 16.0 | 19.0 | 1.188 | 1.146 | 1.188 | ||||
| -30 | 16.0 | 17.0 | 1.06 | -30 | 16.0 | 17.0 | 1.063 | 1.083 | 1.063 | ||||
| -45 | 16.0 | 16.0 | 1.00 | -45 | 16.0 | 16.0 | 1.000 | 1.021 | 1.000 | ||||
| -60 | 16.0 | 16.0 | 1.00 | -60 | 16.0 | 16.0 | 1.000 | 0.979 | 1.000 | ||||
| -75 | 16.0 | 15.0 | 0.94 | -75 | 16.0 | 15.0 | 0.938 | 0.938 | 0.938 | ||||
|
|
|||||||||||||
|
|
|||||||||||||
|
|
|||||||||||||
